Tangless Wire Inserts
|
|
|
|
TANGLESS WIRE INSERT
Tangless CoilThread inserts are made of cold-rolled 304 stainless steel wire (AS7245), work-hardened to a tensile strength above 200,000 psi, and a hardness of Rc 43-50. The finished surface (8-16 micro-inches) is exceedingly smooth, virtually eliminating friction-induced thread erosion.
Assembled metricTangless Coilthread will also accommodate MJ, AS1370 and DIN male threaded fasteners.
|
TANGLESS COIL THREAD WIRE INSERT
The stainless steel used resists corrosion under normal environmental conditions. Galvanic action within the thread assembly is reduced, further adding to the life of the fastening assembly. KATO Inserts are used with temperatures from -320°F to +800°F (-195.6°C to +426.7°C).
|
|
|
TANGLESS WIRE INSERT
Tangless inserts are identical in performance, fit, function and material to convential helically-coiled inserts and install into the same BS4377 tapped holes to accept ISO metric threads conforming to BS3643: Part 1 : 1981 and BS3643: Part 2 : 1981. Metric Tangless CoilThread inserts conform to National Bureau of Standards Handbook H-28/21, M Profile, Tolerance Classes 4H5H or 5H, as well as ISO standards 68, 261, R724 and 965/I. |
TANGLESS WIRE INSERT
When assembled with STI-tapped holes, Tangless CoilThread inserts form Unified Coarse, or Unified Fine threads that conform to the National Bureau of Standards Handbook H-28, Screw-Thread Standards for Federal Services, Classes 2B and 3B. Assembled Tangless CoilThread inserts will also accommodate UNJ, MIL-S-8879, male threaded fasteners.
|
|
|
|
Wire inserts at competitive prices
Aerospace approved and certified products
|
|
|
|
|
